Vertical Machining Centres


Table Size: 200mm
Travel (X, Y, Z): 460 x 410 x 460mm
Travel (A, B): 30 to -120 deg. /360 deg.
Spindle Taper: NST No. 40
Spindle Speed: 200~20,000rpm
Tool Storage Capacity: 174 Pcs. (230,258,314 Opt.) Matrix Style
Tool Change Time (T-T/C-C): 1.3 sec. /2.5 sec.
Rapid Feed  (X, Y, and Z): 60m/min
Rapid Feed (A, B): 18,000 deg./min (50rpm)
Power Requirement: 55KVA

• Horizontal configuration allows flexibility for single set-up, unmanned machining
• Ultra high positioning Accuracy: ±0.000079”/full stroke, Repeatability: ±0.000039”
• Ideal for both unmanned one-off and high quantity production
• Standard 20-station automatic pallet changer with up to 80 pallets available as an option
• Highest grade Meehanite cast iron construction with heavy duty roller linear guide way system
• High speed, built-in, dual contact 20,000rpm spindle
• Work handling system reduces pallet load & unload time, allowing for just-in-time operation
