Table Size: 400 x 560mm
Travel (X, Y, Z) 600 x 510 x 510mm
Spindle Taper: NST No. 40
Spindle Speed: 12,000rpm, NRG Belt Drive
Tool Storage Capacity: 40 Pcs.
Tool Change Time (T-T/C-C): 2.8 Sec./5.2 Sec.
Rapid Feed (X, Y x Z): 48m/min) X/Y x 1,654ipm Z
Power Requirement: 30KVA
• Standard 2-station, factory installed 180 degree rotating APC. Uniquely compact design
• Heavily ribbed stiff cast Meehanite C-Frame construction
• #40, 35HP, 12,000rpm NRG belt driven spindle offers power that exceeds industry standards
• Convenient and flexible standard scraper type chip conveyor
• Operator friendly Kitamura Arumatik-Jr. CNC Controller offers up to 16x faster processing speeds!
