CNC and Manual Slotting Machines

TS-350K Manual Slotting Machine

- Square ram slide way are harden & ground.
- Head can swivel ±30°
- Built in lubrication system to prevent wear.
- 0008 Ram cutting speeds are available to choose suitable slotting speeds.

Indexing ratio  1:80
Max. travel of the ram (stroke)  350mm
No. of strokes per minute (60HZ) spm   L: 22-26-31-39   H: 44-52-61-78
No. of strokes per minute (50HZ) spm  L: 22-26-31-39   H: 44-52-61-78
Vertical adjustment of ram  320
Swivel angle of head  ±30°
Distance between ram guide way & worktable (A)  470mm
Distance between tooling center & column (B) 560mm
Dimension of working table Ø560mm
Longitudinal travel of working table 460mm
Cross travel of working table (Y)  460mm
Main spindle motor (2 speeds motor) 5HP 4P/8P
Net weight 1850kg





CNC-350A1 Single Axis Automatic CNC Slotting Machine

- Powerful WIN-CE touch screen CNC controller,User-friendly, Easy to operate.
- Uses AC servo motor with high precision C3 class ball screw for feeding purpose, best cutting accuracy and long life.
- Program include auto tool relief function for best machining surface and prolonging tool's life.
- Built-in automatic lubrication system to prevent wear.



Indexing ratio  1:80
Max. travel of the ram (stroke)  300mm
No. of strokes per minute (60HZ) spm   L: 22-26-31-39   H: 44-52-61-78
No. of strokes per minute (50HZ) spm  L: 22-26-31-39   H: 44-52-61-78
Vertical adjustment of ram  320
Swivel angle of head  ±30°
Distance between ram guide way & worktable (A)  365mm
Distance between tooling center & column (B) 510mm
Dimension of working table Ø560mm
Longitudinal travel of working table 460mm
Cross travel of working table (Y)  432mm
Main spindle motor (2 speeds motor) 5HP 4P/8P
Net weight 1650/1800kg

CNC-350 3 Axis Automatic CNC Slotting Machine

- X, Y Axis & Ram Slide Way hardened and precision ground.
- Head can swivel ±30° for slotting taper keyway.
- Uses AC-servo motor with high precision C3 ball screw for feeding purpose, best cutting accuracy and long life.
- Program include auto tool relief function for best slotting surface and prolong tool's life.
- Built in automatic lubrication system to prevent wear.



Max. travel of the ram (stroke)  350mm
No. of strokes per minute (60HZ) spm   L: 22-26-31-39   H: 44-52-61-78
No. of strokes per minute (50HZ) spm  L: 22-26-31-39   H: 44-52-61-78
Vertical adjustment of ram  320
Swivel angle of head  ±30°
Distance between ram guide way & worktable (A)  470mm
Distance between tooling center & column (B) 560mm
Dimension of working table Ø560mm
Longitudinal travel of working table 432mm
Cross travel of working table (Y)  432mm
Main spindle motor (2 speeds motor) 5HP 4P/8P
Net weight 1800/1900kg

CNC-550 4 Axis Automatic CNC Slotting Machine

- The main machine structure is made of high quality cast iron, X,Y axis and Ram guideway are hardened and ground.
- All the slideways,main Ram guideway,and X,Y,Z axis ballscrews are complete with automatic lubrication system to ensure the machine running smoothly and long life.
- The machine is equipped with hydraulic clamping system to lock the connection block between linking Rod and Ram.
- The swivel head can rotate right and left smoothly via worm & worm gear for taper keyway slotting purpose.
- The X,Y,Z axis are complete with high precision C3 class double nut ballscrews and precision bearings specially for precision ballscrew to ensure position accuracy.
- The C axis rotary working table is driven by 4.4kw AC servo motor with high torque coupling to directly drive "Dual lead worm shaft" and "high class bronze alloy worm gear set" to ensure the high indexing accuracy.

Max. travel of the ram (stroke)  550mm
Table Diameter 850mm
Max table load 2000kg
Bore of work table Φ250mm
Distance between ram guide way & worktable (A)  875mm
Distance between tooling center & column (B) 650mm
Dimension of working table Ø850mm



CNC-450S 5 Axis Automatic CNC Slotting Machine

- The main machine structure is made of high quality cast iron, X,Y axis and Ram guideway are hardened and precision ground.
- All the slideways,main Ram guideway,and X,Y,Z axis ballscrews are complete with automatic lubrication system to ensure the machine running smoothly and long life.
- The swivel head can rotate right and left direction. to ensure optimal keyway parallelism, It’s also for helical cutting or taper keyway slotting urpose.
-  Use ultra-high load (Axial dynamic load up to 39 tons) high precision ballscrew for Z axis plus full-cycle lubrication system to ensure safe life of ballscrew running.
- CNC-450 S model powered spindle head adopt precision AC servo motor drive 1:2 high precision gear set for high precision indexing accuracy, powerd spindle head use BT50 spindle match with two high accuracy ultra axial load tapered roller bearing to ensure enough heavy slotting force.
-  The X,Y,Z axis are complete with HIWIN high precision C3 class double nuts ballscrews and precision bearings specially for precision ballscrew to ensure position accuracy.
