BV Series Heavy Duty BTA Drilling Machine
BV-Series
For round bar materials, Centerline drilling
Machinery
Energy
Defence
Construction
Oil and gas
Power generation
Transmission
Aerospace
Marine
Automotive
Paper
| Model | BV1-1000 | BV1-2000 |
| Drilling diameter | S: Ø30~110mm O: Ø30~150mm |
S: Ø30~110mm O: Ø30~150mm |
| Drilling depth | 1000mm | 2000mm |
| Numbers of spindle | 1 | 1 |
| 3-jaw chuck size | S: 16″ manual O: 20″ manual |
S: 16″ manual O: 20″ manual |
| Tool rotation | v | v |
| Workpiece rotation | x | x |
| Controller | Mitsubishi / Fanuc | Mitsubishi / Fanuc |
F Series Table Type Gundrilling Machine
F Series
for Off-center holes
Standard accessories
Chip conveyor and cart
Air conditioner for electrical box
Coolant chiller
Coolant pump
Steady rest for tools
Working light
Tool box
English operation manual
| Model | F-1000 |
|---|---|
| Drilling diameter | S: Ø3~25mm O: Ø4~30mm |
| Drilling depth | S: 800mm O: 1000mm O: 1200mm |
| Numbers of spindle | 1 |
| Working table size | 1200 x 800mm |
| Loading capacity | 3000kgs |
| X axis travel | 1000mm |
| Y axis travel | S: 600mm O: 800mm |
| Controller | Mitsubishi / Fanuc |
RS Series Micro Gundrilling Machine
RS-Series
For Micro Drilling
Standard accessories
Chip conveyor and cart
Air conditioner for electrical box
Coolant chiller
Coolant pump
Steady rest for tools
Working light
Tool box
English operation manual
| Model | RS4-300R | RS2-500R |
| Drill diameter | Ø1.5~6mm | Ø1.5~6mm |
| Drill depth | 300mm | 500mm |
| Number of Spindle | 4 | 2 |
| Chuck size | 4" | 7" |
| Tool rotation | V | V |
| Workpiece rotation | V | V |
| Controller system | Fanuc / Mitsubishi | Fanuc / Mitsubishi |
S Series Multi Axis Gundrilling machine
S Series
For Molds and Dies
- 1600mm x 1400mm CNC Rotary Table
- BT-50 milling head with moving column design
Standard accessories
- Column moving (Z axis)
- BT-50 milling head
- 1400 x 1600mm CNC rotary table
- Chip conveyor and cart
- Air conditioner for electrical box
- Coolant chiller
- Coolant pump
- Steady rest for tools
- Working light
- Tool box
- English operation manual
| Model | S-2010 | S-2015 | S-3010 | S-3015 |
| Drilling diameter | S: Ø3~30mm O: Ø4~40mm |
S: Ø3~30mm O: Ø4~40mm |
S: Ø3~30mm O: Ø4~40mm |
S:Ø3~30mm O: Ø4~40mm |
| Drilling depth | 1500mm | 1500mm | 1500mm | 1500mm |
| Gundrill spindle | 1 set | 1 set | 1 set | 1 set |
| BT-50 milling spindle | 1 set | 1 set | 1 set | 1 set |
| Working table size | 1600 x 1800mm | 1600 x 1800mm | 1600 x 1800m | 1600 x 1800mm |
| Loading capacity | 10000kg | 10000kg | 10000kg | 10000kg |
| Degree | 0.001 | 0.001 | 0.001 | 0.001 |
| X-Axis travel | 2000mm | 2000mm | 3000mm | 3000mm |
| Y-Axis travel | 1000mm | 1500mm | 1000mm | 1500mm |
| Controller | Fanuc | Fanuc | Fanuc | Fanuc |
