S Series Multi Axis Gundrilling machine

Deep Hole Drilling

S Series Multi Axis Gundrilling machine

Model S-2010 S-2015 S-3010 S-3015
Drilling diameter S: Ø3~30mm

O: Ø4~40mm
S: Ø3~30mm

O: Ø4~40mm
S: Ø3~30mm

O: Ø4~40mm
S:Ø3~30mm

O: Ø4~40mm
Drilling depth 1500mm 1500mm 1500mm 1500mm
Gundrill spindle 1 set 1 set 1 set 1 set
BT-50 milling spindle 1 set 1 set 1 set 1 set
Working table size 1600 x 1800mm 1600 x 1800mm 1600 x 1800m 1600 x 1800mm
Loading capacity 10000kg 10000kg 10000kg 10000kg
Degree 0.001 0.001 0.001 0.001
X-Axis travel 2000mm 2000mm 3000mm 3000mm
Y-Axis travel 1000mm 1500mm 1000mm 1500mm
Controller Fanuc Fanuc Fanuc Fanuc

S Series
For Molds and Dies
- 1600mm x 1400mm CNC Rotary Table
- BT-50 milling head with moving column design

Standard accessories
- Column moving (Z axis)
- BT-50 milling head
- 1400 x 1600mm CNC rotary table
- Chip conveyor and cart
- Air conditioner for electrical box
- Coolant chiller
- Coolant pump
- Steady rest for tools
- Working light
- Tool box
- English operation manual
