Plasma Cutting

Smart Plasma

Robust... Precise...Economical...

3-axis I High-performance I Gantry type

The EPL Plasma Smart series is a quality and economic sheet metal working machine which meets customers’ expectations by using plasma and oxygen cutting technologies.

- Ergonomic design
- Powerful consumables
- Lower costs
- Productivity
- Efficiency
- Oxygen cutting position



• Hypertherm MicroEDGE ® Pro CNC
• 17’’ LCD industrial type touch screen
• Hypertherm operator panel
• Safety module input and output
• Hypernet communication system
• Remote connection interface
• Phoenix interface
• Metric and inch gauges.
• HyPerformance® MaxPro200 plasma source
• Hypertherm automatic gas console
• ERMAK THC automatic height control system
• Safety input-output interface module
• Nozzle sensor
• Collision sensor
• 200 mm standard stroke
• Laser Pointer
• TurboNest® Cad/Cam software
• 3 Axis (X,Y,Z)
• 3 pieces Mitsubishi AC servo motor and driver
• 3 pieces planet type Neugart gear box
• High accuracy linear rails
• High accuracy an silent Atlanta Helis rack and pinion
• X,Y, Z Axis Igus brand silent cable tray
• Cutting table with pneumatic system
• Moving control panel system
• 2 Emergency buttons
• 6 Mechanical stops

EPL Pipe and Profile Cutting

Impressive solution for Tube Cutting...

Precise cutting I Low cutting cost I Ergonomic design I Simple operation I Filtering system I Marking

- Sensitive and qualified cuts with Hypertherm XD® plasma source
- Meeting the high speed plasma cutting standards with impeccable filtration system thanks to inner pipe suction design.
- High precision for edge cuts and round cuts with the stoned helical cramier and pinion.
- Manuel support system that provides 50 – 400 diameter pipe cuts.
- Advanced Height control unit designed for plasma cutting.
- A design that protects mechanical parts from fumes or impacts.
- Infinity CNC control unit is easy to use and efficient
- Sofware Lantek Cad/Cam
- Marking speciality
- Feature of returning backward and continue to cut where ever needed.
- Large utilization area like tank manufacturing, pipe line etc.

Hypertherm EDGE® Pro CNC
- 15’’ LCD Sanayi Tipi Dokunmatik Ekran
- 15’’ LCD industrial type touch screen
- Hypertherm operator panel
- Safety module input and output
- Hypernet communication system
- Remote connection interface
- Phoenix interface
- Metric and inch gauges.

HyPerformance® HPR130XD® plasma source
- Hypertherm manual gas console
- Plasma marking

Arc Glide™ THC automatic height control system
- Hypernet communication system
- Safety input-output interface module
- Nozzle sensor
- Collision sensor
- 220 mm standard stroke
- Lazer pointer

TurboNest® Cad/Cam Software
3 Axis (X,Y,Z)
- 3 pieces Mitsubishi AC servo motor and driver
- 3 pieces planet type Neugart gear box
- High accuracy linear rails
- High accuracy an silent Atlanta Helis rack and pinion
- X,Y, Z Axis Igus brand silent cable tray

Cutting table with pneumatic system
Moving control panel system
2 Emergency buttons
6 Mechanical stops

EPL 5-Axis Plasma Cutting Machine

Bringing a new dimension to your cutting operations...

True bevel technology I Low cots operation I Ergonomic design I Simple operation I True hole technology

5-Axis cutting head
All angles are calculated automatically with 5-Axis cutting technology. During the cutting process it composes the angle value automatically, which the operator needs to enter. 5-Axis cutting technology is a perfect solution for vertical and angular cuts.

Benefits
- Automatically bolt hole without operator intervention
- Close the gap between the laser hole quality and the plasma process making it a convenient option for many laser cut jobs.
- Completely eliminates the hole tape.
- Resonance is minimal and deflected out of the hole.
- Provides true bolt hole quality

Plasma source 130/260/400/800A
Table dimensions 1.5m to 36m

- True Hole™ technology.
- Low investment cost.
- Maximum efficiency.
- 2-3 times more parts produced per hour.
- 15” touch screen Hypertherm®EDGE®PRO controller.
- TurboNEST®plasma generator and torch system for precise cuts.
- Hypertherm®plasma generator and torch system for accurate cuts.
- Lower cutting costs compared to your competitors.
- Hundreds of machines working all around the world.
- Easy installation and training.
- Durable choice for your precise cutting works.
