TLE-30FS Injection Moulding Machine
• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot for part or sprue (option)
• Phase motion control Ultract hydraulic drive
| Screw Diameter | 25mm |
| Shot Volume (Theoretical) | 40cm3 |
| Injection Weight (PS) | 37g |
| Injection Rate | 46g/s |
| Injection Pressure | 212Mpa |
| Screw Speed | 0-250r/min |
| Clamping Unit Clamping Tonnage | 300KN |
| Toggle Stroke | 240mm |
| Space Between Tie Bars | 280*260mm |
| Max. mould Height | 290mm |
| Min. mould Height | 100mm |
| Ejector Stroke | 61mm |
| Ejector Tonnage | 27KN |
| Max Pump Pressure | 14Mpa |
| Pump Motor Power | 11KW |
| Heater Power | 3.2 KW |
| Machine Dimension (LxWxH) | 1.65x0.96x1.4m |
| Machine Weight | 1.4T |
TLE-50FS Injection Moulding Machine
• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot for part or sprue (option)
• Phase motion control Ultract hydraulic drive
| Screw Diameter | 30mm |
| Shot Volume | 75cm3 |
| Injection Weight (PS) | 68g |
| Injection Rate | 82g/s |
| Injection Pressure | 213Mpa |
| Screw Speed | 0-320r/min |
| Clamping Tonnage | 500KN |
| Toggle Stroke | 280mm |
| Space Between Tie Bars | 308*308mm |
| Max.mould Height | 320mm |
| Min.mould Height | 120mm |
| Ejector Stroke | 70mm |
| Ejector Tonnage | 27.5mm |
| Max Pump Pressure | 16Mpa |
| Pump Motor Power | 11KW |
| Heater Power | 3.6KW |
| Machine Dimension (LxWxH) | 3.2x1.31x1.8m |
| Machine Weight | 2.3T |
TLE-100FS Injection Moulding Machine
• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot for part or sprue (option)
• Phase motion control Ultract hydraulic drive
| Screw Diameter | 38mm |
| Shot Volume (Theoretical) | 187cm3 |
| Injection Weight (PS) | 68g |
| Injection Rate | 170g/s |
| Injection Pressure | 186Mpa |
| Screw Speed | 0-250r/min |
| Clamping Tonnage | 1000KN |
| Toggle Stroke | 285mm |
| Space Between Tie Bars | 355*315mm |
| Max.mould Height | 370mm |
| Min.mould Height | 125mm |
| Ejector Stroke | 85mm |
| Ejector Tonnage | 33KN Max |
| Pump Pressure | 16Mpa |
| Pump Motor Power | 15KW |
| Heater Power | 5.5KW |
| Machine Dimension (LxWxH) | 4x1.4x1.9m |
| Machine Weight | 3T |
TLE-120FS Injection Moulding Machine
• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot for part or sprue (option)
• Phase motion control Ultract hydraulic drive
| Screw Diameter | 40mm |
| Shot Volume (Theoretical) | 187cm3 |
| Injection Weight (PS) | 170g |
| Injection Rate | 138g/s |
| Injection Pressure | 201Mpa |
| Screw Speed | 0-360r/min |
| Clamping Tonnage | 1200KN |
| Toggle Stroke | 380mm |
| Space Between Tie Bars | 385*350mm |
| Max.mould Height | 410mm |
| Min.mould Height | 150mm |
| Ejector Stroke | 85m |
| Ejector Tonnage | 33KN |
| Max Pump Pressure | 16Mpa |
| Pump Motor Power | 18KW |
| Heater Power | 7.2KW |
| Machine Dimension (LxWxH) | 4x1.43x1.9m |
| Machine Weight | 3.5T |
TLE-130FS Injection Moulding Machine
• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot for part or sprue (option)
• Phase motion control Ultract hydraulic drive
| Screw Diameter | 42mm |
| Shot Volume (Theoretical) | 259cm3 |
| Injection Weight (PS) | 235g |
| Injection Rate | 152g/s |
| Injection Pressure | 182Mpa |
| Screw Speed | 0-315r/min |
| Clamping Unit Clamping Tonnage | 1300KN |
| Toggle Stroke | 380mm |
| Space Between Tie Bars | 415*415mm |
| Max.mould Height | 450mm |
| Min.mould Height | 150mm |
| Ejector Stroke | 130mm |
| Ejector Tonnage | 33KN |
| Max Pump Pressure | 16Mpa |
| Pump Motor Power | 18KW |
| Heater Power | 7.5KW |
| Machine Dimension (LxWxH) | 4.5x1.48x1.9m |
| Machine Weight | 4.2T |
TLE-150FS Injection Moulding Machine
• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot for part or sprue (option)
• Phase motion control Ultract hydraulic drive
| Screw Diameter | 45mm |
| Shot Volume (Theoretical) | 297cm3 |
| Injection Weight (PS) | 270g |
| Injection Rate | 221g/s |
| Injection Pressure | 159Mpa |
| Screw Speed | 0-400r/min |
| Clamping Tonnage | 1500KN |
| Toggle Stroke | 435mm |
| Space Between Tie Bars | 460*460mm |
| Max.mould Height | 500mm |
| Min.mould Height | 180mm |
| Ejector Stroke | 152mm |
| Ejector Tonnage | 40KN |
| Max Pump Pressure | 16Mpa |
| Pump Motor Power | 22KW |
| Heater Power | 7.5KW |
| Machine Dimension (LxWxH) | 4.9x1.52x1.9m |
| Machine Weight | 5.2T |
TLE-170FS Injection Moulding Machine
• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot for part or sprue (option)
• Phase motion control Ultract hydraulic drive
| Screw Diameter | 50mm |
| Shot Volume (Theoretical) | 392cm3 |
| Injection Weight (PS) | 357g |
| Injection Rate | 246g/s |
| Injection Pressure | 143Mpa |
| Screw Speed | 0-320r/min |
| Clamping Tonnage | 1700KN |
| Toggle Stroke | 435mm |
| Space Between Tie Bars | 460*460mm |
| Max.mould Height | 500mm |
| Min.mould Height | 180mm |
| Ejector Stroke | 152mm |
| Ejector Tonnage | 40KN |
| Max Pump Pressure | 16Mpa |
| Pump Motor Power | 22KW |
| Heater Power | 9.7KW |
| Machine Dimension (LxWxH) | 5.1x1.52x2.1m |
| Machine Weight | 5.5T |
TLE-220FS Injection Moulding Machine
• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot for part or sprue (option)
• Phase motion control Ultract hydraulic drive
| Screw Diameter | 55mm |
| Shot Volume (Theoretical) | 522cm3 |
| Injection Weight (PS) | 475g |
| Injection Rate | 289g/s |
| Injection Pressure | 152Mpa |
| Screw Speed | 0-286r/min |
| Clamping Tonnage | 2200KN |
| Toggle Stroke | 480mm |
| Space Between Tie Bars | 520*520mm |
| Max.mould Height | 560mm |
| Min.mould Height | 200mm |
| Ejector Stroke | 150mm |
| Ejector Tonnage | 62KN |
| Max Pump Pressure | 16Mpa |
| Pump Motor Power | 30KW |
| Heater Power | 11.1KW |
| Machine Dimension (LxWxH) | 5.6x1.63x2.2m |
| Machine Weight | 6.8T |
TLE-280FS Injection Moulding Machine
• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot for part or sprue (option)
• Phase motion control Ultract hydraulic drive
| Screw Diameter | 65mm |
| Shot Volume (Theoretical) | 895cm3 |
| Injection Weight (PS) | 814g |
| Injection Rate | 385g/s |
| Injection Pressure | 143Mpa |
| Screw Speed | 0-250r/min |
| Clamping Tonnage | 2800KN |
| Toggle Stroke | 550mm |
| Space Between Tie Bars | 580*560mm |
| Max.mould Height | 610mm |
| Min.mould Height | 220mm |
| Ejector Stroke | 140mm |
| Ejector Tonnage | 62KN |
| Max Pump Pressure | 16Mpa |
| Pump Motor Power | 37KW |
| Heater Power | 15.6KW |
| Machine Dimension (LxWxH) | 5.8x1.76x2.2m |
| Machine Weight | 8T |
TLE-320FS Injection Moulding Machine
• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot for part or sprue (option)
• Phase motion control Ultract hydraulic drive
| Screw Diameter | 65mm |
| Shot Volume (Theoretical) | 895cm3 |
| Injection Weight (PS) | 814g |
| Injection Rate | 385g/s |
| Injection Pressure | 143Mpa |
| Screw Speed | 0-250r/min |
| Clamping Tonnage | 3200KN |
| Toggle Stroke | 585mm |
| Space Between Tie Bars | 660*640mm |
| Max.mould Height | 710mm |
| Min.mould Height | 220mm |
| Ejector Stroke | 125mm |
| Ejector Tonnage | 62KN |
| Max Pump Pressure | 16Mpa |
| Pump Motor Power | 37KW |
| Heater Power | 15.6KW |
| Machine Dimension (LxWxH) | 6.3x2x2.4m |
| Machine Weight | 11.5T |
TLE-360FS Injection Moulding Machine
• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot for part or sprue (option)
• Phase motion control Ultract hydraulic drive
| Screw Diameter | 68mm |
| Shot Volume (Theoretical) | 1161cm3 |
| Injection Weight (PS) | 1057g |
| Injection Rate | 448g/s |
| Injection Pressure | 185Mpa |
| Screw Speed | 0-289r/min |
| Clamping Tonnage | 3600KN |
| Toggle Stroke | 585mm |
| Space Between Tie Bars | 660*640mm |
| Max.mould Height | 710mm |
| Min.mould Height | 220mm |
| Ejector Stroke | 125mm |
| Ejector Tonnage | 62KN |
| Max Pump Pressure | 16Mpa |
| Pump Motor Power | 37+18KW |
| Heater Power | 17.3KW |
| Machine Dimension (LxWxH) | 6.8x1.8x2.6m |
| Machine Weight | 12.5T |
