Cylindrical Grinding

BUB E CNC Grinding Machine

BUB E CNC is a fully CNC controlled 3-Axis grinding machine with X-Axis (grinding wheel head in-feed), Z-Axis (longitudinal table feed), and C-Axis (grinding wheel peripheral speed).

The BUB E is primarily designed for controlled grinding of cylindrical and conical external surface workpieces using longitudinal or plunge-cut grinding methods. Form grinding and grinding of various transitions among different diameters can be performed. The grinder also allows grinding of face surfaces and cylindrical and conical internal holes using the internal grinding attachments (other version). The workpieces may be clamped between centers or by flying-mode into the chuck. The drive headstock as well as grinding wheel head and upper table may be inclined for grinding cones. It is possible to grind either at the centers or in the flying-mode with the workpiece clamped in the chuck or on the magnetic plate.

The grinding wheel head and table are moved in a line by ball screws and servomotors. The BUB E CNC is designated for workpieces weighing up to 500kg.

Swing diameter 320/400/500(600)mm
Distance between centers 1000/1500/2000mm
Max. weight of workpiece 500kg
Wheel head swivel +45°/-15° (manual)
Max. number of used tools 1+1
Grinding wheel dimensions  500x80x203mm
Wheel head motor power 11kW






BHM 50 2000 CNC Grinding Machine

The BHM Grinder is designed for controlled grinding of cylindrical and conical external surfaces of medium-weight workpieces by use of longitudinal or plunge-cut grinding methods. Form grinding and grinding of various transitions among different diameters can be performed. The BHM also allows grinding of face surfaces and cylindrical and conical internal holes by using the internal grinding attachments. The workpieces may be clamped between centers or by using flying-mode into the chuck. The drive headstock as well as grinding wheel head may be inclined for grinding cones. It is possible to grind either at the centers or in flying-mode with the workpiece clamped in the chuck or on the magnetic plate.

The grinding wheel head and table are moved in the line by ball screws and servomotors. The BHM CNC is designated for workpieces weighing up to 1000kg.



Swing diameter 500(600)mm
Distance between centers 1000/1500/2000/3000mm
Max. weight of workpiece 1000kg
Wheel head swivel +15/°-180° (manual)
Max. number of used tools 1+1
Grinding wheel dimensions 500x80x203mm
Wheel head motor power  11kW





BUC E CNC Grinding machine

The BHM Grinder is designed for controlled grinding of cylindrical and conical external surfaces of medium-weight workpieces by use of longitudinal or plunge-cut grinding methods. Form grinding and grinding of various transitions among different diameters can be performed. The BHM also allows grinding of face surfaces and cylindrical and conical internal holes by using the internal grinding attachments. The workpieces may be clamped between centers or by using flying-mode into the chuck. The drive headstock as well as grinding wheel head may be inclined for grinding cones. It is possible to grind either at the centers or in flying-mode with the workpiece clamped in the chuck or on the magnetic plate.

The grinding wheel head and table are moved in the line by ball screws and servomotors. The BUC E CNC is designated for workpieces weighing up to 3 000kg.

Swing diameter 630 / 850mm
Distance between centers 2000 / 3000 / 4000 / 5000mm
Max. weight of workpiece 3000kg
Wheel head swivel +30°/-10°(manual)
Max. number of used tools 1+1
Grinding wheel dimensions 750 x 100 x Ø 305mm
Wheel head motor power 18.5kW







BHRC Cylindrical Grinder - 5 ton

With controlled B-Axis.

The BHCR is a fully CNC controlled grinding machine with controlled X-Axis (grinding wheel head in-feed), Z-Axis (longitudinal table feed), controlled C-Axis (grinding wheel peripheral speed), and controlled B-Axis that can be equipped with up to 3 grinding tools which enables very high productivity.

Designed primarily for CNC controlled grinding performed on external cylindrical surfaces of various diameters, and their adjoining face areas and radiuses, including automatic dressing by the CNC dresser, and stabilization via the CNC system. The machine can be equipped with automatic balancing system, in-process gauge, axial probe, super finish attachment, automatic (electric) rests, XZ ruler etc.

The BHCR can perform grinding with longitudinal feed and a moving table, plunge-cut grinding with a fixed or oscillating table, grinding in the cycle of plunge-cut,and longitudinal grinding.

The grinding wheel head feed-in and table carriage are driven by servomotors and ball screws. The BHCR center grinding machine represents a very stable and accurate machine that can be used for a series production applications, including single-part production for workpieces up to 4000 kg. 5000kg optional.

Swing diameter 630/850/1000/1200mm
Distance between centers 2000/3000/4000/5000/6000mm
Max. weight of workpiece 4000/5000kg
Wheel head swivel +45°/-225°(automatic)
Max. number of used tools 3
Grinding wheel dimensions 750x100x305mm
Wheel head motor power 18,5kw



BHC Cylindrical Grinder - 5 ton

Without controlled B-Axis.

The BHCR is a fully CNC controlled grinding machine with controlled X-Axis (grinding wheel head in-feed), Z-Axis (longitudinal table feed), controlled C-Axis (grinding wheel peripheral speed).

Designed primarily for CNC controlled grinding performed on external cylindrical surfaces of various diameters, and their adjoining face areas and radiuses, including automatic dressing by the CNC dresser, and stabilization via the CNC system. The machine can be equipped with automatic balancing system, in-process gauge, axial probe, super finish attachment, automatic (electric) rests, XZ ruler etc.

The BHC can perform grinding with longitudinal feed and a moving table, plunge-cut grinding with a fixed or oscillating table, grinding in the cycle of plunge-cut,and longitudinal grinding.

The grinding wheel head feed-in and table carriage are driven by servomotors and ball screws. The BHC center grinding machine represents a very stable and accurate machine that can be used for a series production applications, including single-part production for workpieces up to 4000 kg. 5000kg optional.

Swing diameter 630/850/1000/1200mm
Distance between centers 2000/3000/4000/5000/6000mm
Max. weight of workpiece 4000/5000kg
Wheel head swivel +30°/-30°(manual)
Max. number of used tools 1+1
Grinding wheel dimensions 750x100x305mm
Wheel head motor power 18,5kw




GU32 X 60NC

  • Stable and Rigid Spindle Head
  • The spindle runs on precision bearings, assuring maximum spindle stability.
  • The spindle head swivels +90°~-30°.
  • The spindle head on the 20 series machines provides variable speed changed by frequency inverter.
  • The spindle head on the 32 and 42 series is driven by servomotor, providing variable speed.
  • Precision Wheel Head
  • The grinding wheel spindle is precision machined from high quality alloy steel SNCM-220, normalized, tempered, carburized and sub-zero treated, precision ground and mirror-effect treated.
  • Special Hydrostatic Bearing
  • The wheel spindle runs by using a special hydrostatic bearing and is especially ideal for precision grinding work.
  • Advanced Hydrostatic Lubrication System
  • The slideways of the table and the wheel head are lubricated by an advanced automatic hydrostatical lubrication system.
Distance Between Centers 600mm
Swivel Over Table 320mm
Max. Load of Centers 100kg
Max. External Grinding Diameter 280mm
Swivel Angle ±30°
Manual Distance 160mm
Speeds (belt-type) 1783rpm
Spindle Speeds (variable) 16~450rpm
Max. Load of Spindle    35kg (Max length: 150mm)
Traverse Speed    50~4000mm/min



GU20 X 40S

Features

  • Stable and Rigid Spindle Head
  • The spindle head swivels +90°~-30°.
  • Precision Wheel Head
  • Special Hydrostatic Bearing
  • Advanced Hydrostatic Lubrication System
Distance Between Centers     400 mm
Swivel Over Table     200 mm
Max.Load of Centers 60 kg
Max. External Grinding Diameter 160 mm
Swivel Angle                            ±30°
Manual Distance                       135 mm
O.D x Width x I.D                         305 x 38 x 127 mm
Speeds (belt-type) r.p.m                     2085 / 2495
Center Taper                             MT: 3
Traverse Speed                             50 ~ 4000 mm/min
Internal Grinding Spindle                     0.375 kw (2P)
Coolant Tank                             100 L
Wheel Spindle Lubricant Tank                         12 L
Wheel Spindel                             2.1 kw (4P)
Machine Weight            2000 kg



OCD3260

Features

  • Rigid Spindle Head
  • It guarantess outstanding accuracy for external and interna diameter grinding and face grinding.
  • The spindle head on the OPTMUM series cylindrical grinder is driven by servomotor, providing variable speed change.
  • The spindle head allows for swiveling positive 90° and negative 30°.
  • Precision Wheel Spindle
  •  Wheel Spindle with Hydro-static Bearing Absolutely No Metal-to-Metal Contact
  • Tailstock Lubrication System Simplifies Maintenance
Swing Over Table Ø320 mm
Distance Between Centers 600 mm
Max. Grinding Diameter Ø300 mm
Max. Load Held Between Centers 150 kg
Wheel OD x Width x ID Ø405 x 50 xØ127 mm
Linear Velocity 30 m/s
Speed 1783rpm
Rapid Feedrate 6m/min
Speed 10-300rpm
Max. Load of Spindle(tool holder included) 35kg(Max length:150 mm)
Center MT. No. 4
Tailstock Stroke 25 mm
Coolant Pump 0.18(4P)kw
Wheel Spindle Bearing Lubricant 18L
Machine Weight 3600 kg



OCD3235A

Features

  • Special hydro-static Bearing
  • The wheel spindle runs by using a special hydro-static bearing and is expecially ideal for precision grinding work. It features high speed, no friction between metals, no heat generation, deformation-free, extra high accuracy with continual use.
  • X and Z Axis simultaneous movement may dress the wheel in specific shape for multiple-step grinding purpose.
  • Angular Type Wheel Seat
  • Independent hydraulic and lubrication system, with hydro-static slide ways and high precision ball screws to ensure ultra high positioning accuracy.
  • Applicable with FANUC / SIEMENS / MITSUBISHI controller.
Swing Over Table     Ø320 mm
Distance Between Centers     350 mm
Max. Grinding Diameter     Ø300 mm
Max. Load Held Between Centers     150 kg
Wheel OD x Width x ID     Ø455 x 75 x 152.4 mm
Linear Velocity     33 m/s
Speed     1400 rpm
Wheelhead Rapid Feedrate     6 m/min
Min. Input Increment     0.001 mm / 0.0001 mm
Speed 10 ~ 300 RPM
Max. Load of Spindle(tool holder included) 35kg
Wheel spindle     7.5 HP x 4P
Hydraulic tank     18 L
Weight     60 L
Machine Weight     5000 kg



GU32X60S

Feature

  •  Stable and Rigid Spindle Head
  • The spindle runs on precision bearings, assuring maximum spindle stability. It guarantees outstanding accuracy for external and internal diameter grinding and face grinding.
  • The spindle head swivels +90°~-30°.
  • The spindle head on the 20 series machines provides variable speed changed by frequency inverter.
  • The spindle head on the 32 and 42 series is driven by servomotor, providing variable speed.
  • Precision Wheel Head
  • The grinding wheel spindle is precision machined from high quality alloy steel SNCM-220, normalized, tempered, carburized and sub-zero treated, precision ground and mirror-effect treated. Hardness reaches to over HRC 62°. No deformation, maximum wear resistance and lifetime accuracy are assured.
  • Special Hydrostatic Bearing.
  • Advanced Hydrostatic Lubrication System.
Distance Between Centers     600 mm
Swivel Over Table     320 mm / 420 mm
Max.Load of Centers     100 kg
Max. External Grinding Diameter     280 mm / 380 mm
Swivel Angle     ±30°
Manual Distance     160 mm
Auto Rapid Advance     40 mm
Sliding Seat Supplementary Displacement   95 (total 295 mm)
Min. Setting Unit     0.001 mm
Grinding Wheel O.D x Width x I.D     355 x 50 x 127 mm
Center Taper     MT:4
Wheel Spindel     3.75 kw (4P)
Hydraulic Fluid Tank     65 L
Coolant Tank     100 L
Machine Weight  2600 kgs / 2800 kgs
