Surface Grinding

WD Hearn has been representing Kent Surface Grinding products for over 25 years now

KGS250 AHD

KGS250 AHD (Auto Head Down)

  • Automatic down feed, known as Auto Head Down (AHD)  for fully automatic 3 Axis operation with spark out
  • Machine base, table, saddle and column are made from MEEHANITE cast iron with precision heat treatment for constant accuracy
  • Saddle cross ways are of double V design, lined with Turcite-B, hand scraped to assure slip-free movement
  • Crossfeed leadscrew is hardened and precision ground to provide optimal accuracy
  • Table moves on ball bearings, hardened slideways and specially selected balls to ensure smooth movement
  • Separate hydraulic unit avoids the transmission of heat or vibration to the machine
  • Resettable longitudinal handwheel
  • Cross-feed locking mechanism
  • Two axes fine feed mechanism
  • Parallelism and flatness accuracy 0.0002"
  • Available with Magnetic Seperator and paper filtration system
  • WD Hearn have been selling Kent Surface Grinders for over 20 years with outstanding customer feedback
KGS 63 AHD

KGS 63 AHD (Generally Ex Stock )

  • Automatic down feed, known as Auto Head Down (AHD)  for fully automatic 3 Axis operation with spark out
  • Machine base, table, saddle and column are made from MEEHANITE cast iron with precision heat treatment for constant accuracy
  • Saddle cross ways are of double V design, lined with Turcite-B, hand scraped to assure slip-free movement
  • Crossfeed leadscrew is hardened and precision ground to provide optimal accuracy
  • Table moves on ball bearings, hardened slideways and specially selected balls to ensure smooth movement
  • Separate hydraulic unit avoids the transmission of heat or vibration to the machine
  • Resettable longitudinal handwheel
  • Cross-feed locking mechanism
  • Two axes fine feed mechanism
  • Parallelism and flatness accuracy 0.0002"
  • Available with Magnetic Seperator and paper filtration system
  • WD Hearn have been selling Kent Surface Grinders for over 20 years with outstanding customer feedback

KGS 84AHD

Featuring:

  • Automatic down feed for fully automatic 3 Axis operation, adjustable in 5 steps
  • Machine base, table, saddle and column are made from MEEHANITE cast iron with precision treatment for constant accuracy
  • Table longitudinal ways are one flat and one "V" way,lined with Turcite-B, hand scraped to assure slip-free movement
  • Saddle cross ways are Double V design, lined with Turcite-B, hand scraped to assure slip-free movement
  • Crossfeed leadscrew is hardened and precision ground to provide optimal accuracy
  • Separate hydraulic unit avoids the transmission of heat or vibration to the machine
  • Electronic cross feed control
  • Automatic lubrication
  • Full length rear splash guard
  • Special Package includes: Halogen work light, 16 x 32" Electromagnetic chuck and chuck control, Over the wheelhead HYDRAULIC dresser, Magnetic system and coolant system, Full length rear guard

Standard Accessories:

  • Above listed Special Package Items
  • Wheel balancing base
  • Wheel balancing arbor
  • Grinding wheel,and wheel flange
  • Table dresser
  • Leveling pads and bolts
  • Halogen work light
  • One set of maintenance tools
  • Manual

KGS-1020AHD

Featuring:

  • Automatic down feed for fully automatic 3 Axis operation, adjustable in 5 steps
  • Machine base, table, saddle and column are made from MEEHANITE cast iron win precision treatment for constant accuracy
  • Table longitudinal ways are one flat and one "V" way,lined with Turcite-B, hand scraped to assure slip-free movement
  • Saddle cross ways are Double "V" design, lined with Turcite-B, hand scraped to assure slip-free movement
  • Crossfeed leadscrew is hardened and precision ground to provide optimal accuracy
  • Separate hydraulic unit avoids the transmission of heat or vibration to the machine
  • Special Package includes: Full length splash guard, Halogen work light, 10 x 20" Electro Mg. Chuck with chuck control, Parallel dresser, Magnetic separator coolant tank

Standard Accessories:

  • Above listed Special Package Items
  • Wheel balancing base
  • Wheel balancing arbor
  • Grinding wheel,and wheel flange
  • Table dresser
  • Leveling pads and bolts
  • Halogen work light
  • One set of maintenance tools
  • Manual

Wizzard Series - WM1

Features:



● Three axes automatic grinder with small footprint.

● Castings are made of high quality ribbed cast iron.

● The elevation guide ways (Y axis) are hardened and ground.

● The spindle is supported by P4 preloaded super precision angular contact ball bearings to guarantee a maximum 2 micron run out.

● Hydraulic system with a specially designed valve enables smooth table reversing with a 30meter/min table speed.

● Separate hydraulic unit and cooling device prevent temperature rise of hydraulic oil and permits easy maintenance.

● Standard hydraulic over-head wheel dresser.

● Automatic lubricating system to ensure smooth and long lasting operation in all 3-axes.

● Mitsubishi PLC will provide years of reliable and trouble-free operation.

● Modern 6- inch color LCD touch screen panel, simply touch the screen to set the grinding variables.

● Down feed mechanism is driven by an AC servomotor with grade C5 precision ball-screw, with minimum 0.001mm increment capacity.

● Manual Pulse Generator (MPG) is also provided for user’s convenience.

● The crossfeed travel is set by the push-button on the console; different crossfeed increments can be set for both rough and finish grinding.

● The control system will store the last grinding cycle in memory. Simply press the cycle start button to repeat the previous operation.

● Control also available in two axes.

● Sizes available from ( 250~400 )mm by ( 500~800 )mm.

WM2 Series - Saddle Traveling Type

Features:



● Three axes automatic grinder with small footprint.

● Castings are made of high quality ribbed cast iron.

● The elevation guide ways (Y axis) are hardened and ground.

● The spindle is supported by P4 preloaded super precision angular contact ball bearings to guarantee a maximum 2 micron run out.

● Hydraulic system with a specially designed valve enables smooth table reversing with a 30meter/min table speed.

● Separate hydraulic unit and cooling device prevent temperature rise of hydraulic oil and permits easy maintenance.

● Standard hydraulic over-head wheel dresser.

● Automatic lubricating system to ensure smooth and long lasting operation in all 3-axes.

● Mitsubishi PLC will provide years of reliable and trouble-free operation.

● Modern 6- inch color LCD touch screen panel, simply touch the screen to set the grinding variables.

● Down feed mechanism is driven by an AC servomotor with grade C5 precision ball-screw, with minimum 0.001mm increment capacity.

● Manual Pulse Generator (MPG) is also provided for user’s convenience.

● The crossfeed travel is set by the push-button on the console; different crossfeed increments can be set for both rough and finish grinding.

● The control system will store the last grinding cycle in memory. Simply press the cycle start button to repeat the previous operation.

● Control also available in two axes.

● Sizes available from ( 250~400 )mm by ( 500~800 )mm.
