Machine Travels X x Y x Z  600x400x310mm
Maximum Workpiece Dimensions 1050x820x305mm
Max. Submerged Workpiece Weight 1500kg
Table Dimensions 840x560mm
Table Rapid Feed Speed     1300mm/min
Minimum Drive Unit/Resolution     0.000002/2µin (0.00005/50nm)
Wire Diameter Possible 0.1~0.3mm
Minimum Start Hole Diameter 0.5mm
Machine System Dimensions 2687x3030mm
Machine Installed Height 2150mm
Machine System Weight 3500kg
Fluid System Weight 350kg


• 600 x 400 x 310mm (425mm OPT) travels, complete with AWT as standard
• Improved machining accuracy -Optical Drive System - Next-generation drive system and refined power-supply control technology
• Improved productivity -Precise Finish Circuit- Wide range of technologies for ever-changing working environments
• Easy operation -Natural User Interface- User-friendly features ensure easy operation
• Energy savings, low running cost -Long Life System- Realizing low costs and environment-friendly operation
