CKE6150Z x 1500

CNC Flat Bed Turning Center

CKE6150Z x 1500

Max. swing over slide 280mm
Bed width 400mm
Spindle taper D8
Spindle speeds 7-2200 1/min
Spindle bore 82mm
Transmission ratio 3 steps (auto)
Tailstock quill diameter 75mm
Taper of tailstock quill 5 MK
Tailstock quill stroke 150mm
Max. length of work piece 1500mm
X-travel 280mm
Z travel  1430mm
  • All main components, bed, headstock, saddle, plinth etc are high quality solid castings
  • Low friction Turcite-B coating on all surfaces between saddle and guideways
  • Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability
  • Centralised oil system provides forced automatic lubrication onto ballscrews and surfaces
  • Choice of two model ranges. THE CKE-Z series has automatic headstock gear change, wide range high spindle speed and low noise levels of under 80db. The CKE-i series, with independent spindle structure, utilises a frequency converted spindle motor or servomotor to offer stepless high spindle speeds.
  • Operator adjustable control panel enables convenient tool setting
  • Fully enclosed guards with interlock offer a waterproof and chip-free environment
  • Horizontal 4-P automatic indexing toolpost is provided as standard, while vertical 4-P toolpost, horizontal 6-P toolpost, quick-change toolpost etc can also be supplied to suit customers’ specific requirements
  • Optional pneumatic or hydraulic chuck and tailstock are available
