Slant Bed Turning Centers

A Turning Center with its spindle in a horizontal position. This is the most common type of turning center configuration. The Horizontal Turning Centers are further divided into Slant Bed or Flat Bed (Teach Lathe Type), and the selection of machine is dependent on the type of material , length of part and quantities required. Slant Bed Lathes are the more popular configuration of machine for production shops, and flat beds lathes are often found in shops doing small quantities of low value shafts.

T-5i

  • Available as Gang Type or Turret Type high speed linear way turning center
  • Available with Siemens 828D Basic or Fanuc Oi control systems
  • True One-piece Cast Iron Construction
  • High Precision Cartridge Type Spindle for easy servicing
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • Available with or without Tailstock
  • C-axis with Live tool turret available as an option
  • Sub-Spindle configuration available as an option
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Powerful, compact, mass production turning center with a number of references in South Africa

Brochure

Brochure

PDF icon T-5 New.pdf

Specifications

Specifications

Capacity  330mm
Bar Capacity 35mm
Chuck size 6inch
X axis 230mm
Z axis 105+20mm
Spindle speed 45-4500rpm
Hole through spindle 62mm
Number of tool positions 12
X rapid traverse     20m/min
Z rapid traverse 24m/min
Spindle Motor 15HP

Video

Video

T-6A

  • Most popular size compact Linear Way Turning Center, available with Siemens 828D or Fanuc Oi
  • A2-5 / 52mm Bar Capacity with 6" or 8" chuck
  • True One Piece Cast Iron Construction
  • 36m/min Rapid Traverse
  • Cartridge Type Spindle for easy servicing
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T series machines
  • Hydraulic or Servo Type Turret available with 20 x 20mm Tooling
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • C-axis with Live Tooling Option
  • Available ex-stock (Subject to Prior Sale )

Specifications

Specifications

Max swing 500mm
Bar capacity 51mm
X axis 190+20mm
Z axis 460mm, 460mm
Spindle speeds range 6000rpm
Chuck size 152in

T-7A

  • High Speed, Powerful compact turning center available with Siemens or Fanuc
  • A2-6 / 65mm Bar Capacity with 8" or 10" chuck
  • True One Piece Cast Iron Construction
  • 36m/min Rapid Traverse
  • Cartridge Type Spindle for easy servicing
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T series machines
  • Hydraulic or Servo Type turret available with 25 x 25mm Tooling
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • C-axis with Live Tooling Option
  • Available ex-stock (Subject to Prior Sale )

Specifications

Specifications

Max swing 500mm
Bar capacity 65mm
X axis 190+20mm
Z axis 450mm
Spindle speeds range 4000rpm
Chuck size 203in

Video

Video

T-8XL

  • Largest Linear Way Model from Leadwell with Powerful Motor configuration
  • Available with a 1050mm Turning Length
  • A2-8 / 85mm Bar Capacity with 10" or 12" chuck
  • Option of 101mm Bar Capacity with ZF Gear Box and 1" chuck available
  • True One Piece Cast Iron Construction
  • 36m/min Rapid Traverse
  • Cartridge Type Spindle for easy servicing
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter and programmable Tailstock is an option on T series machines
  • Hydraulic or Servo Type turret
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • C-axis with Live Tooling Option
  • Available ex-stock (Subject to Prior Sale )

Specifications

Specifications

Max. swing 670mm
Bar capacity 77mm
X axis 225+25mm
Z axis 1050mm
Spindle speeds range 3500rpm
Chuck size 254mm

Video

Video

LTC-20

  • Heavy Duty Turret - The T/LTC series turret features a robust casting and a large coupling face adding extra rigidity to the machine
  • Cast Iron Construction
  • Cartridge Type Spindle
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • Live Tooling Option
  • C-Axis Option

Specifications

Specifications

Max swing 450/500/450/540mm
Bar capacity  65/65/65/65mm
X axis 160+10/190+20/160+10/160+20mm
Z axis 540/540/540/540mm
Spindle speeds range 4000/4000/4000/4000mm
Chuck size 8/8/8/8mm

Video

Video

LTC-25

  • Heavy Duty Turret - The T/LTC series turret features a robust casting and a large coupling face adding extra rigidity to the machine
  • Cast Iron Construction
  • Cartridge Type Spindle
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • Live Tooling Option
  • C-Axis Option

Specifications

Specifications

Max swing     637mm
Bar capacity  77mm
X axis 225+15mm
Z axis 790/1050/1550/2050mm
Spindle speeds range 3500rpm
Chuck size 254mm

Video

Video

LTC-35

  • Heavy Duty Turret - The T/LTC series turret features a robust casting and a large coupling face adding extra rigidity to the machine
  • Cast Iron Construction
  • Cartridge Type Spindle
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • Live Tooling Option
  • C-Axis Option

Specifications

Specifications

Max. swing 800mm
Bar capacity 115mm
X axis travel  300+20mm/344+10mm/215+25
Z axis travel 1100/1600/2100/3100/4100mm
Spindle speed 2000rpm
Chuck size 382mm

Video

Video

LTC-50

  • Heavy Duty Turret - The T/LTC series turret features a robust casting and a large coupling face adding extra rigidity to the machine
  • Cast Iron Construction
  • Cartridge Type Spindle
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • Live Tooling Option
  • C-Axis Option

Specifications

Specifications

Max swing 900/900/850/850mm
Bar capacity 117mm
X axis   400+25mm
Z axis 1100/2100/3100/4100mm
Spindle speeds range 1500rpm
Chuck size 381mm/457mm

Video

Video

LTC60

  • Heavy Duty Turret - The T/LTC series turret features a robust casting and a large coupling face adding extra rigidity to the machine
  • Cast Iron Construction
  • Cartridge Type Spindle
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • Live Tooling Option
  • C-Axis Option

Specifications

Specifications

Max. swing 1020mm
Bar capacity 117mm
X axis travel 400+28/437+18/VDI 60430+25/BMT 75320+10mm
Z axis travel 5000/6000mm
Y axis travel ±100mm
Spindle speed 1500rpm
Chuck size  533mm

T-7i

  • High Precision compact turning center available with Siemens or Fanuc
  • A2-6 / 65mm Bar Capacity with 8" or 10" chuck
  • True One Piece Cast Iron Construction
  • Servo Type Turret as standard.
  • 36m/min Rapid Traverse
  • Cartridge Type Spindle for easy servicing
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • C-axis with Live Tooling Option
  • Available ex-stock (Subject to Prior Sale )

Specifications

Specifications

Max swing 520mm
Bar capacity 66mm
X axis 210+10mm
Z axis 540mm
Spindle speeds range 4500rpm
Spindle Chuck size A2-6/8”
Turret 12
CT1

CT1

A new standard in precision machining

  • 45 degree slant bed structure for excellent stability
  • Roller type linear guideways with excellent repeatability
  • Chiah Chyun self-designed and manufactured live turrets

Specifications

Specifications

Max. manu. dia. Ø330mm
Standard manu. dia. Ø210mm
Swing over bed diameter  Ø846mm
Distance between two center 1061mm
Max. manu. length 740mm
Bar capacity F: Ø65    M: Ø76
X axis travel  230mm
Z axis travel  603mm
Y axis travel ±50mm
B axis travel 744.5mm
X, Y, Z axis rapid travel speed  16/6/40m/min
B axis rapid travel speed 40m/min
Spindle max rpm 4000rpm
Spindle bore F: Ø86    M: Ø88
Spindle bar capacity F: Ø65    M: Ø76
Chuck Size 8"
Sub Spindle max. 4000rpm
Sub Spindle bore  Ø86
Spindle bar capacity Ø65
Chuck Size 8"
C axis rapid travel speed  600min-1


Video

Video

CT2-52YM

CT2-52YM

  • Double turret with 16-station live tooling
  • Single Y axis
  • Double built-in spindle
  • Built-in Type Spindle - The built-in spindle performing short accelerate/decelerate time and low vibration characteristic, it provide high precision and high efficient capability.
  • Motor: 7.5/11kw
    • 6000rpm (standard) / 4000rpm (optional)
    • A2-5 spindle nose
    • Spindle cooling
  • Oil Mist Lube System

The oil mist lube system provides lubrication oil for the gears in the turret, that supply for reducing the mist continuously and lower the temperature of gear.

Specifications

Specifications

Max. manu. dia.  ∅330mm
Standard manu. dia ∅210mm
Swing over bed diameter  ∅830mm
Distance between two center 920mm
Max. manu. length  400mm
Bar capacity  ∅51
X1, X2, X3 axis travel   227.5/230mm
Z1, Z2, Z3 axis travel   440/440mm
Y1, Y2 axis travel ± 50mm
X, Y, Z axis rapid travel speed  650mm
B axis rapid travel speed 16/6/40m/min
Min. input unit  40m/min
Spindle max.  0.001
Spindle bore  6000rpm
Spindle bar capacity  ∅60.5
Chuck size  6"/8"
Spindle max. 6000rpm
Spindle bore ∅60.5
Spindle bar capacity ∅51
Chuck size  6"/8"
C axis rapid travel speed   600min-1
Live tool rpm  60~6000min-1
No. of  live tools  16 × 2
Collet size ER∅32


Video

Video

CT3-52Y2M

Features

  • Twin spindle & Three Turret
    CT3 can perform complex machining faster and more economically in one setup.
  • Whether you produce complex or simple parts at high production rates, CT3 with twin spindle and three turrets offers unbeatable versatility. This machine consists of three 16-position servo turrets that will dramatically upgrade machining efficiency and maximize productivity.

Specifications

Specifications

Max. manu. dia.     Ø330 mm
Standard manu. dia.    Ø210 mm
Swing over bed dia.     Ø830 mm
Distance between two center     1045
Max. manu. length     320
Bar capacity    Ø51
X1, X2, X3 axis travel     227.5/230/227.5
Z1, Z2, Z3 axis travel     310/440/250
Y1, Y2axis travel     ± 50/± 50
B axis travel     762
X, Y, Z axis rapid travel speed    16 / 6 / 40 m/min
Max. spindle speed     4000rpm
Machine size(LxWxH) (includes chip conveyor)     4327x2335x2164
Power     67KVA
Machine N.W.
(includes chip conveyor)
11120kgs



Video

Video

CT3-76Y2M

Feature

  • Twin spindle & Three Turret
  • CT3 can perform complex machining faster and more economically in one setup.
  • Whether you produce complex or simple parts at high production rates, CT3 with twin spindle and three turrets offers unbeatable versatility. This machine consists of three 16-position servo turrets that will dramatically upgrade machining efficiency and maximize productivity.

Specifications

Specifications

Max. manu. dia.     Ø330 mm
Standard manu. dia.     Ø210 mm
Swing over bed dia.     Ø830 mm
Distance between two center     1045
Max. manu. length 300
Bar capacity Ø76
X1, X2, X3 axis travel     227.5/230/227.5
Z1, Z2, Z3 axis travel 285/425/250
Y1, Y2axis travel     ± 50/± 50
B axis travel 680
X, Y, Z axis rapid travel speed     16 / 6 / 40 m/min
B axis rapid travel speed     40m/min
Max. spindle speed 4000rpm
Spindle nose     A2-6
Machine size(LxWxH) (includes chip conveyor)     4327x2335x2164



Video

Video

WTS-52Y2M

Features

  • Twin Spindle & Twin Turret & Double Y Axis
  • E-Axis for 2 Separate Work Areas
  • Double Y Axis 16-Station Upper and Lower Turrets

Specifications

Specifications

Max. manu. dia.      ∅370mm
Standard manu. dia.      ∅210mm
Swing over bed dia.      ∅780mm
Distance between two center of spindle nose      814mm
Max. manu. length      500mm
Bar capacity      ∅51mm
X1/X2-axis travel      215/230mm
Z1/Z2-axis travel      550/550mm
Y1,Y2-axis travel      ± 50mm
B-axis travel      550mm
E-axis travel      170mm
Max. spindle speed      6000rpm
Spindle nose      A2-5
Power      220V, 80KVA, 3phase
Machine size(LxWxH) (includes chip conveyor)      4162*2265*2226



About Company

Our clients range from FTSE companies, to large organisations and some small local businesses who are striving to expand.

To see a detailed list of our works and the progress please see our project page.

Cape Town Office

25 Mail Street, Western Province Park, Epping, Cape Town, 7460
+27 21 534 5351
FAX: +27 21 534 3374

Johannesburg Office

Corner of Atlas and Templehof South Road, Bonaero Park, Johannesburg
+27 11 970 7005
FAX: +27 86 678 9360
