Multi Tasking Turning Center

Multitasking machines are designed to provide a certain desired machining strategy by using any combination of milling and turning within the same work envelope. They are usually recognizable as a Horizontal or Vertical Lathe, with spindles for milling and drilling simply available at some or all of the tool positions. With a Multi Tasking machine, a part requiring a variety of operations can be machined in one setup, particularly if a subspindle allows the part to be passed from one spindle to another during machining.

CT3-65Y2M

CT3-65Y2M

  • Double Built-in Spindle with 65 model
  • Double Y axis for versatile milling
  • Three Servo Turret
  • Total 48 Station Live Tooling

Specifications

Specifications

Max. Manu. Dia. Ø210
Standard Manu. Dia. Ø190
Max. Swing Dia. Ø210
Distance Between Two Center 1045mm
Max. Manu. Length 320mm
Bar Capacity Ø51
X1, X2, X3 Axis Travel 227.5/230/227.5mm
Z1, Z2, Z3 Axis Travel 310/440/250mm
Y1, Y2 Axis Travel ±50mm
B Axis Travel 762mm
X, Y, Z Axis Rapid Travel Speed 16/6/40m/min
B Axis Rapid Travel Speed 40m/min
Max. Spindle speed 6000rpm
Spindle Motor  7.5/11kw
Spindle Bore Ø60.5
Spindle Bar Capacity     Ø51
Max. Sub Spindle speed 6000rpm
Spindle Motor 7.5/11kw

Video

Video

CY2-52MB (With B-axis for angle hole drilling )

Features

  • The CY2-52MB CNC turning milling center combines double built-in spindle, double Y axis and B axis live tooling functions. This milling center can greatly reduce machining time and raise overall production efficiency.
  • The B axis live tooling system provides high precision for indexing accuracy up to 0.001° and can rotate 360°, supplying angular machining capability.

Specifications

Specifications

Max. manu. dia.      Ø51mm
Bar capacity      Ø51mm
Spindle max. rpm       6000 rpm
X1 axis travel     200mm
Y1 axis travel      455mm
Z1 axis travel      192mm
Max. bar feeding dia.       Ø51mm
Collet of spindle      TRB-52
X1, Y1, Z1 rapid travel speed      30 m/min
No. of Axial and Radial driven tool     12
Sub spindle Max. manu. dia.       Ø51
Machine N.W. (includes chip conveyor)      6000 kg
Machine size (LxWxH) (includes chip conveyor)     3400x1921x2080





Video

Video

Multicut 500i

Multicut 500i

The MULTICUT 500i S is a powerful turning-milling machine that allows for a combination of turning, milling and boring operations in a single machine, with one clamping setup.

The modular system allows for custom supply of the machine, either with a counter-spindle - “S” design, or with a tailstock - “T” design. The suitable combination of synchronized movements of the working and tool spindles fulfils almost all technological requirements for turning, threading, recessing, drilling, boring, milling, cam milling, toothing rolling, groove and toothing machining, grinding and measuring, including the capacity to machine thin shafts with steady rest support.

Specifications

Specifications

Max. swing over bed  1030mm
Max. turning diameter 549/690/880/1030mm
Max. turning length 1693/1527mm
Bar capacity 94mm
X/Y/Z axis travel 640/370/1600mm
X / Y / Z axis rapid traverse 50/40/50m/min
Position accuracy X/Y/Z 0,008/0,007/0,01mm
Repeatability X/Y/Z  0,004/0,004/0,008mm
Max. spindle speed 13500
Nominal spindle speed 1750
Spindle bore 106mm
Subspindle
Max. spindle speed 3500
Nominal spindle speed 750
Spindle boring mm 106mm



Video

Video

Multicut 630

Multicut 630

MULTICUT 630 is available in two kinematic variants:
S-version with the right spindle
T-version with the tailstock
These multioperational turning-milling centers combine turning and milling in a single universal machine which has capability to machine complex parts using more technologies (turning, threading, recessing, drilling, boring, milling, cam milling, gear hobbing, grinding and measuring). The machines are equipped with a B-axis as standard which allows an extra-axial drilling and 5-axis milling. The MULTICUT 630 S (with the right spindle) can do a full part machining on both sides.

Specifications

Specifications

multicut 630 1500/3000/4500/6000
Max. turning dia.  790/930/1060/1150mm
Max. turning length 1600/3100/4600/6100mm
Spindle power 78/61.5/49/41kw
Spindle speed 720/2800min-1
Maximum torque 881/762/622/518Nm
Tool changer, places 44 / 66
Max. tool length 500mm
Max. tool diameter 130/200mm
Machine weight    (kg) 20 000/25 000/30 000/35 000



Video

Video

TM 1500

Features

  • The multi-function machine with B-axis can easy have bevel angle drilling and cutting work.
  • The B-axis is driven by DD build-in motor, the best torque is 1200Nm, and with curved coupling it can easy do a heavy cutting job shop work and also curved surface milling.
  • The machine use special Electro Spindle, the spindle speed can reach 12000rpm and torque 103Nm, it is a special machine can do first mill and end mill in the same machine.
  • The Y-axis design is perpendicular type, and match with our moving column machine structure, the Y-axis have complete movement.  It will not have dead space for the travel. (Y-axis travel +/-220mm).(applying for patent now.)
  • 12”chuck (C-axis) + servo tailstock (M.T #5) + 40 tools ATC (Capto C6) + 1550mm Z-axis travel + B-axis (-100°~+140°)=Perfect machine.

Specifications

Specifications

Max. swing                    mm (in)         790(31)
Max. turning diameter     mm (in)         780(30.7)
Bar capacity                  mm (in)     115(4.5)
X/Z/Y axis travel            mm (in)     730+40(28.7+1.57)/1550(61)/±200(7.87)
B axis travel mm (in)      mm (in)     240゜(-10゜~+230゜)
Spindle speed (chuck/electro)    rpm 1500/12000
Chuck size    mm (in)         381(15)
Type of spindle nose     A2-11
Spindle motor power    Kw(hp) 30(40)
Tool storage capacity     40
X/Z/Y axis rapid traverse    m/min(imp) 20/30/20(787.4/1181/787.4)



Video

Video

TW 8

Features

  • Twin Spindle & Turret Turning Center

Specifications

Specifications

Max. swing                mm (in) 290(11.42)
Max. turning diameter mm (in) 290(11.42)
Max. turning length     mm (in) 160(6.3)
X axis travel               mm (in) 145+10(8.86+0.59)
Z axis travel               mm (in) 165(31.1)
Spindle speed             rpm. 4500
Chuck size                 mm (in) 210(8)






Video

Video
