CNC Flat Bed Turning Center

Flat bed turning centers are designed for machining on relatively hard, heavy duty materials with large turning lengths. They were originally designed for the machining of metals, however, bacause of their natural versatility and the advent of plastics and other materials, are now used in a wide range of applications, on a broad range of materials. Flat Bed Turning Centers are generally considerably cheaper than their slant bed counterparts., especially when the workpiece length is over 1000mm in length. They are commmonly found with CNC systems with conversatinal programming such as Siemens (Shopturn) or Fagor.

CKE6150Z x 1500 mm

  • All main components, bed, headstock, saddle, plinth etc are high quality solid castings
  • Low friction Turcite-B coating on all surfaces between saddle and guideways
  • Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability
  • Centralised oil system provides forced automatic lubrication onto ballscrews and surfaces
  • Choice of two model ranges. THE CKE-Z series has automatic headstock gear change, wide range high spindle speed and low noise levels of under 80db. The CKE-i series, with independent spindle structure, utilises a frequency converted spindle motor or servomotor to offer stepless high spindle speeds.
  • Operator adjustable control panel enables convenient tool setting
  • Fully enclosed guards with interlock offer a waterproof and chip-free environment
  • Horizontal 4-P automatic indexing toolpost is provided as standard, while vertical 4-P toolpost, horizontal 6-P toolpost, quick-change toolpost etc can also be supplied to suit customers’ specific requirements
  • Optional pneumatic or hydraulic chuck and tailstock are available

Brochure

Specifications

Specifications

Max. swing over slide 280mm
Bed width 400mm
Spindle taper D8
Spindle speeds 7-2200 1/min
Spindle bore 82mm
Transmission ratio 3 steps (auto)
Tailstock quill diameter 75mm
Taper of tailstock quill 5 MK
Tailstock quill stroke 150mm
Max. length of work piece 1500mm
X-travel 280mm
Z travel  1430mm

Video

Video

CKE6136

Features

  • All main components, bed, headstock, saddle, plinth, etc., are high quality solid castings
  • Low friction Turcite-B coating on mating surfaces between saddle and guideways.
  • Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability.
  • Centralized oil system provides forced automatic lubrication onto ballscrews and all mating surfaces.
  • Operator adjustable control panel enables convenient tool setting.
  • Optional pneumatic or hydraulic chuck and tailstock are available.

Brochure

Specifications

Specifications

Max. Swing over bed                   630 mm
Width of bed                    550 mm
Max. Length of work piece              1000 mm
X travel                          320 mm
Z travel                          2735 mm
Spindle nose                      C11
Chuck size                       320 mm
Taper of spindle bore                  1:20
Spindle bore                       100 mm
Frequency conversion motor power           11 kW
Rapid traverse X/Z                  4/8 m/min
Repeatability of tool post                   0.008 mm
Diameter of tailstock quill                   100mm
Travel of tailstock quill                   240mm
Taper of tailstock quill                 M6
Net weigh                       4500 Kg



Video

Video

CKE 6140Z x 1000mm (Generally Ex Stock)

Feature

  • Available with Siemens 808D, Siemens 828D Basic (Shopturn) , Fanuc Oi , Fagor control systems
  • 394mm Width of Bed
  • 1000mm Workpiece Length
  • All main components, bed, headstock, saddle, plinth, etc., are high quality solid castings.
  • Low friction Turcite-B coating on mating surfaces between saddle and guideways.
  • Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability.
  • Centralized oil system provides forced automatic lubrication onto ballscrews and all mating surfaces.
  • Operator adjustable control panel enables convenient tool setting.

Brochure

Specifications

Specifications

Max. Swing over bed                      400 mm
Width of bed                         300 mm
Max. Length of work piece                   1000 mm
Max. Swing over slide                      200 mm
X travel                             225 mm
Z travel                               680mm
Spindle nose                         D6
Chuck size                          200 mm
Taper of spindle bore                      M6
Spindle bore                          52 mm
Steps of spindle speed                      2-step actuator
Frequency conversion motor power               5.5 kW
Rapid traverse X/Z                       4/5m/min
Repeatability of tool post                      0.008 mm
Horizontal 6-position Tool post changing time         3
Diameter of tailstock quill                      63mm
Travel of tailstock quill                       130mm



Video

Video

CKE 6150Z x 2000mm

Features

  • All main components, bed, headstock, saddle, plinth, etc., are high quality solid castings.
  • Low friction Turcite-B coating on mating surfaces between saddle and guideways.
  • Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability.
  • Centralized oil system provides forced automatic lubrication onto ballscrews and all mating surfaces.
  • Operator adjustable control panel enables convenient tool setting.
  • Optional pneumatic or hydraulic chuck and tailstock are available.



Specifications

Specifications

Max. Swing over bed                     400 mm
Width of bed                          300 mm
Max. Length of work piece                   2000 mm
Max. Swing over slide                       200 mm
X travel                              225 mm
Z travel                             680mm
Spindle nose                         D6
Chuck size                          200 mm
Taper of spindle bore                      M6
Spindle bore                          52 mm
Steps of spindle speed                     2-step actuator
Frequency conversion motor power               5.5 kW
Rapid traverse X/Z                      4/5m/min
Repeatability of tool post                       0.008 mm
Horizontal 6-position Tool post changing time
Diameter of tailstock quill                       63mm
Travel of tailstock quill                       130mm
Taper of tailstock quill                      M4
Net weigh                           1800Kg
Overall dimensions                      2300 x1480 x1520mm



Video

Video

CKH 6156 X 1000

Features

  • The machine adopts horizontal straight bed layout. Main machine bodies, i.e. bed, leg, etc are made of resin sand-casting through timing treatment, which ensures superb-stability of the machine.

Specifications

Specifications

Max. swing over bed  560 mm
Max. swing over cross slide  330 mm
Distance between centers  1000 mm
Spindle bore diameter 82 mm
Spindle speed 3-3000rpm
Main Motor power 11/15 kw



CKH 6156 X 2000

Feature

  • The machine adopts horizontal straight bed layout. Main machine bodies, i.e. bed, leg, etc are made of resin sand-casting through timing treatment, which ensures superb-stability of the machine.

Specifications

Specifications

Max.Swing over bed  560 mm
Max. Swing over cross slide 330 mm
Distance between centers 2000mm
Spindle bore diameter 82 mm
Spindle speed  3-3000 rpm
Main motor speed  11/15 Kw



CKH 6180 X 1000

Feature

  • The machine adopts horizontal straight bed layout. Main machine bodies, i.e. bed, leg, etc are made of resin sand-casting through timing treatment, which ensures superb-stability of the machine.

Specifications

Specifications

Max.Swing over bed  800 mm
Max.Swing over cross slide  490 mm
Distance between centers 1000 mm
Spindle bore diameter 105 mm
Spindle speed  2-150 rpm
Main Motor Power  15/18.5 kW



CKH 6180 X 4000

Feature

  • The machine adopts horizontal straight bed layout. Main machine bodies, i.e. bed, leg, etc are made of resin sand-casting through timing treatment, which ensures superb-stability of the machine.



Specifications

Specifications

Max. Swing over bed  800 mm
Max. Swing over cross slide 490 mm
Distance between centers  4000 mm
Spindle bore diameter 105 mm
Spindle speed 2-1500 rpm
Main motor power  15/18.5 kW
